Ohaus Explorer Balances EX10201

Attention: This process is only needed for 1, 2 and 3 decimal scales.

Place the load cell in front of you, as shown in the picture below.

Remove the screw on your left side.

Remove the screw on the right side.

Remove both screws with shims completely from the load cell.

Store the screws and shims in a safe place.

Connect a functioning Power Adapter to the balance

Plug the Power Cord into a suitable power source

Did the balance start up sequence occur properly?

Use a broad blade to remove the label from a corner

Ensure not to cut into the plastic Housing or yourself

Work slowly to allow adhesive time to release

Wear eye protection when using a knife

Clean the glue residue from the Housing surface

Use a section of the adhesive on the removed label to pick up remaining adhesive

Use knife or fingers to roll up remaining adhesive

If adhesive smears, use a cotton cloth to pick up as much as possible

Enter the service menu and adjust settings

Record Auto Zero Tracking Setting

Test Procedure for Non-Approved Models

Ensure the balance has passed the Precision and Repeatability Tests

Ensure the balance is calibrated before performing the Linearity Test

Record the weight of the Reference Mass on the Balance

Remove the Reference Mass from the Balance

Place Load 1 on the Balance and press TARE

Record the weight of the test mass on the Balance after placing Load 1

Remove the test mass from the Balance
