Noblelift Pallet Truck FE4P70N

Eyewinker removed from the motor shell

Carbon brushes and commutator checked for wear

Check the Overhead guard and load backrest for deformation, cracking, damage

Check Indicator light for steering for proper operation

Check horn for proper operation

Check Lamps and bulbs for proper operation

Check Reversing Buzzer for proper operation

Check Instrument working condition

Sign off on the pallet truck check

Check Gearbox and Wheel Reducer for noises

Check Gearbox and Wheel Reducer for leakage

Check the working condition of brake

Check wheel bolt tightening torque

Check brake pedal for Empty run

Check brake pedal Operation condition

Check Whether there is air in the brake pipe

Check Whether the brake is safe and has enough travel

Check Operation condition of the stop, brake and control

Check brake pump Leakage situation

Sign off on the brake system check

Check if there are nails, stones or other foreign items on tire matter

Check if mounting bolts are loose

Check whether the rear axle mounting bolts are loose

Check if there is bending, deformation, cracks or damage

Check the junction with the frame bolts loose situation every 200 Hours / 1 Month

Check Electrical connection loose 200 Hours / 1 Month

Sign off on the wheel system check
