The John Deere Tractor 5100E is a versatile and reliable agricultural machine designed for various farming tasks. Known for its durability and efficiency, this tractor model offers exceptional performance in the field, making it an essential asset for modern agricultural operations.

Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for John Deere Tractor 5100E

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents & Manuals

Find all the essential guides in one place.

Tensioning Guide
Belt-diagram
C-120 pulleys
+ 13 more

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

Daily Electrical System Inspection
Replace Roller and Pulley
Install Engine B-120
+ 29 more

Procedures

Integrate maintenance plans directly into your work orders.

Motion Industries
Applied Industrial Technologies
Electrical Brothers
+ 5 more

Parts

Access the parts list for your equipment in MaintainX.

Drive Motor
B2 Rollers
Tensioning System
+ 40 more

John Deere Tractor 5100E

Create an account to install this asset package.

Maintenance Plans for John Deere Tractor Model 5100E

Integrate maintenance plans directly into your work orders in MaintainX.

500 Hourly Maintenance

Change Engine Oil and Filter

1. Operate engine to warm oil.

2. Park machine on level ground and shut off engine.

3. Remove key.

4. Place a container under the drain port, capture waste oil and dispose of properly.

5. Remove drain plug (A) and allow oil to drain.

6. Open hood.

7. Remove engine oil filter (B). Make sure that old filter gasket is removed from housing before installing new filter.

8. Apply a film of oil on the new oil filter gasket and install new filter. Hand-tighten plus 1/2 turn.

Run this procedure

250 Hourly Maintenance

Activated Carbon Filters

Operate engine to warm oil

Park machine on level ground and shut off engine

Remove key

Place a container under the drain port, capture waste oil and dispose of properly

Remove drain plug (A) and allow oil to drain

Change Engine Oil and Filter

Open hood

Remove engine oil filter (B). Make sure that old filter gasket is removed from housing before installing new filter

Run this procedure

10 Hourly / Daily Maintenance

Check Engine Oil Level

Clean Air Filter Dust Unloading Valve

Park machine on level ground and shut off engine.

Raise hood.

Squeeze the end of the dust unloading valve (A) open and remove any excessive buildup of dust and dirt. Replace if damaged.

Lower hood.

Drain Water and Sediment from Fuel Tank and Fuel Filter

Park machine on level ground and shut off engine. Remove key.

Open fuel tank drain plug (A) to bleed accumulated moisture and sediment from the fuel tank. Tighten plug when clear fuel runs from fitting.

Run this procedure

4500 Hourly Maintenance

Flush Cooling System and Replace Thermostat

Clear all debris from area around DEF tank header

Disconnect coolant hoses from fittings (A and D)

Disconnect DEF return and supply lines from fittings (B and C)

Disconnect DEF tank header electrical connector

Remove vent hose from fitting (E)

Remove cap screws from DEF tank header locking ring (A)

Remove DEF tank header (C) from tank

Remove O-rings (B) and inspect for damage

Run this procedure

1200 Hourly Maintenance

Check Fan Belt Tensioner

1. Place machine in park and shut off engine. Remove key.

2. Remove fan belt.

3. Put a mark on swing arm (A) of the tensioner as shown.

4. Measure 21 mm (0.83 in) from mark on swing arm (A) and put a mark on tensioner mounting base (B).

5. Rotate the swing arm using a torque wrench until marks (A and B) are aligned. Pull tensioner with torque wrench away from engine.

6. Record torque wrench measurement and compare with specification. If recorded measurement is below specifications, have your John Deere dealer replace tensioner assembly.

7. Install fan belt. (See Replace Fan Belt in this section.)

Change Transmission/Hydraulic Oil and Filter

Run this procedure
