John Deere Combines S760

Replace open crankcase ventilation Final Tier 4/Stage IV machines only

Replace Open Crankcase Ventilation Filter (Final Tier 4/Stage V 6.8 L Engine)

Pull hood release (A) and raise hood.

Remove open crankcase ventilation filter from inside the filter housing (B).

To install new filter, align tabs on the new filter with tabs on inside of the filter housing.

Replace Open Crankcase Ventilation Filter (Final Tier 4/Stage V 9.0 L Engine)

Replace hydrostatic and hydraulic filters

Replace hydraulic reservoir fill cap

Adjust engine valve clearance in every 2000 Hours

Replace crankshaft vibration damper in every 5000 Hours or 5 years

Drain, flush, and refill engine cooling system in every 6000 Hours or 6 years

Drive machine at 40 km/h (25 mph) or above for 15 —20 minutes

Park machine on a flat, level surface

Allow hubs to cool to a point that the oil can be handled safely (approximately 30 minutes)

Rotate hub until the casting arrow is pointed to the two o'clock position (A)

Remove drain plug (B) and drain oil into a suitable container

Reinstall drain plug. Tighten to specification

Warning: This procedure requires trained personnel with PPE!

Equalizing element (A) removed and discarded

Check inside of the filter for color code

Filter tool (A) inserted into the filter (B) until a click is felt or heard

Dosing unit threads and mating surfaces cleaned with distilled water

New filter O-rings lubricated with clean engine oil

New filter and equalizing element installed

Park machine on level ground. Stop engine and remove key.

Remove fill cap (A) and clean oil from dipstick.

Install fill cap, then remove and check oil level on dipstick.

Oil level is adequate if level is between the ADD hole (C) and FULL hole (D).

If oil level is below the ADD hole, then add engine oil and recheck until level is adequate.
