Ingersoll Rand Upright Rammer RX-264H

It is recommended that the following steps be performed at the beginning and end of each 8 to 10 hour shift or daily, whichever comes first.

• Check the engine’s oil level at the start of each day and maintain it to the full mark on the dipstick. Insert the dipstick and check the full mark on the dipstick.

• If the machine is operating in a dusty environment check the air cleaner daily. Keep the Air Cleaner Element clean. Take out the outer urethane foam and inner element. Wash the element in kerosene or diesel fuel.

• Saturate it in a mixture of 3 parts kerosene or diesel fuel and 1 part engine oil.

• Shake off excessive oil and reinstall. Wash the air cleaner case using kerosene. After cleaning it up, apply the engine oil on the inner part of the case.

CAUTION! If the air cleaner element is seriously contaminated, the start-up failure, poor output and malfunctions of the engine may result.

Ensure the machine is located on a stable level surface and stopped before proceeding.

Oil level at the upper level (to the neck of oil filler)?

If oil level is below the lower level, refill with the proper oil.

Engine stopped before changing oil?

Drain plug removed and old oil drained?

Drain plug reinstalled before refilling oil?

New oil added at the oil gauge port?

Always use the best grade and clean oil. Contaminated oil, poor quality oil and shortage of oil cause damage to engine or shorten the engine life.

Enter the capacity of engine oil (RX-264H: 0.28 liters / RX-344H: 0.6 liters)

Check the oil level with the oil gauge before each operation.

Capacity of oil – RX-264H: 0.6 liters / RX-344H: 0.9 liters

Drain out the oil and fill with the fresh oil.

After fill with the fresh oil, check each part for the oil leak.

Check the oil level with the oil gauge

Select the model of the machine

Drain out the oil and fill with the fresh oil

Check each part for the oil leak

Sign off on the oil replacement

Is the machine located on a stable level surface and stopped?

Is the oil level below the lower level line?

If yes, refill with the proper oil to the upper level (to the neck of oil filler).

Did you stop the engine, remove the drain plug, drain the old oil and reinstall the drain plug before refilling oil?

Add new oil at the oil gauge port.

Did you use the best grade and clean oil?

Contaminated oil, poor quality oil and shortage of oil cause damage to engine or shorten the engine life.

Enter the capacity of engine oil – RX-264H: 0.28 liters / RX-344H: 0.6 liters
