Ingersoll Rand Thermo Star Refrigarated Air Dryer TS100
Create an account to install this asset package.
Maintenance Plans for Ingersoll Rand Thermo Star Refrigarated Air Dryer Model TS100
Integrate maintenance plans directly into your work orders in MaintainX.
1 Monthly Compressor Maintenance
For optimum performance from your dryer follow the periodic maintenance schedule described below.
Enter the compressor head temperature when running
Is the compressor head temperature between 59°F (15°C) and 131°F (55°C)?
If the temperature is not within the specified range, consult section 7, troubleshooting.
1 Weekly Condensate Drain
Warning: For trained personnel only
Does the condensate drain correctly?
If the condensate does not drain correctly, follow the steps below.
Disassemble and clean the filters
Disassemble and clean the solenoid valves
Disassemble and clean the condensate drain
Check the electrical circuit
Sign here to confirm the completion of the procedure
4 Monthly Air Dryer Maintenance
• For optimum performance from your dryer follow the periodic maintenance schedule described below.
1. Condenser
• Remove any dust from the condenser fins.
2. Compressor
• Make sure compressor power consumption complies with data plate specifications.;
1 Yearly Air Dryer Condensate Drain
For optimum performance from your dryer follow the periodic maintenance schedule described below.
Completely disassemble the drain and clean all its components.
Clean the filters, solenoid valves and condensate drain.
Check the electrical circuit.
Sign off on the maintenance
Parts for Ingersoll Rand Thermo Star Refrigarated Air Dryer TS100
Access the parts list for your equipment in MaintainX.
Timed Soleniod Drain
42512095
Refrigerant Condenser
89328298
Compressor 208/230V 1 Ph ~ 60Hz
38003588
Compressor 115V 1Ph ~ 60Hz
38003562
Fan Motor Run Capacitor
38027785
Timed Soleniod Drain
42512095
Refrigerant Condenser
89328298
Compressor 208/230V 1 Ph ~ 60Hz
38003588
Compressor 115V 1Ph ~ 60Hz
38003562
Fan Motor Run Capacitor
38027785
Timed Soleniod Drain
42512095
Refrigerant Condenser
89328298
Compressor 208/230V 1 Ph ~ 60Hz
38003588
Compressor 115V 1Ph ~ 60Hz
38003562
Fan Motor Run Capacitor
38027785
