Ingersoll Rand Mobile Compressor 17/235

WARNING: Do not remove the filter(s) without first making sure that the machine is stopped and the system has been completely relieved of all air pressure.

• Disconnect all hoses and tubes from the separator tank cover plate.

• Remove the drop–tube from the separator tank cover plate and then remove the cover plate. Remove the separator element.

• Examine the filter element. Examine all hoses and tubes, and replace if necessary.

• Thoroughly clean the orifice/drop tube and filter gasket contact area before reassembly. Install the new element.

WARNING! Do not remove the staple from the anti–static gasket on the separator element since it serves to ground any possible static build–up.Do not use gasket sealant since this will affect electrical conductance.

WARNING: Do not remove the filter(s) without first making sure that the machine is stopped and the system has been completely relieved of all air pressure.

• Clean the exterior of the filter housing and remove the spin–on element by turning it in a counter–clockwise direction.

CAUTION: If there is any indication of the formation of varnishes, shellacs or lacquers on the filter element, it is a warning that the compressor lubricating and cooling oil has deteriorated and that it should be changed immediately. Refer to LUBRICATION later in this section.

• Clean the filter gasket contact area and install the new element by screwing in a clockwise direction until the gasket makes contact with the filter housing. Tighten a further 1/2 to 3/4 of a revolution.

CAUTION: Start the machine and check for leakage before the machine is put back into service.;

Check Air Cleaner Precleaner Dumps

Check Battery Connections/Electrolyte

Sign off on the mobile compressor maintenance

Warning: This maintenance check requires trained personnel!

Verify, during full–load (maximum compressed air delivery) that the IQ System filter restriction indicators do not show excessive restriction.

Restriction indicators for the filters are mounted inside the control panel.

Restriction indicators will shut down the compressor if restriction exceeds recommended values.

Sign off on the daily IQ system maintenance
