Ingersoll Rand Air Compressor R90IU-125

• Unscrew the retaining nut and withdraw the old elements

• Fit the new element ensuring that the retaining nut is secured

• Unclip the retaining cap and withdraw the old elements)

. Fit new elements) and refit the retaining cap.

Unscrew the retaining nut and remove the cannister lid

Warning: Do not operate unit past this 1000 hour change interval, as coolant degradation will occur.

Enter the current hours of operation

Enter the date of the last coolant change

If coolant change is due, proceed with the following steps:

Was the coolant replacement successful?

Sign off on the coolant replacement

NOTE: On some sea water cooled models the oil cooler and after cooler are fitted with sacrificial zinc anodes (pencils) that are located in the end bonnets of the coolers. These sacrificial zinc anodes should be checked after the first 50 hours of operation to determine if corrosive conditions exist. If satisfactory this interval may be extended to 500 hours.

Is the sacrificial zinc anode less than 50% corroded?

Coastal/harbour waters can contain corrosive chemicals from pollution and may reduce anode/cooler life.

Effects of corrosion or erosion are specifically excluded from warranty considerations.

Sign off on the 500 Hourly Zinc Anode Check

Take coolant sample for fluid analysis

Check scavenge screen for blockage, clean if required

Check the calibration of the pressure transducer

Sign off on the air compressor maintenance

Is the coolant level visible in the sight glass while the machine is running on load?

Is the coolant level between the middle and the top of the green section of the sight glass tube?

Did you run the compressor for a minimum of 40 seconds before stopping?

Did you add coolant until the level is up to the mid-point of the sight glass?

Did you perform a visual check of the machine for any leaks, dust build up or unusual noise/vibration?

Sign off on the daily coolant level check
