Ingersoll Rand Air Compressor R90IU-10

Warning: Do not operate unit past this 1000 hour change interval, as coolant degradation will occur.

Enter the current hours of operation

Enter the date of the last coolant change

Sign off on the coolant replacement

NOTE: On some sea water cooled models the oil cooler and after cooler are fitted with sacrificial zinc anodes (pencils) that are located in the end bonnets of the coolers. These sacrificial zinc anodes should be checked after the first 50 hours of operation to determine if corrosive conditions exist. If satisfactory this interval may be extended to 500 hours.

Is the sacrificial zinc anode 50% corroded?

If sacrificial zinc anode is 50% corroded it should be replaced.

Are you operating in coastal/harbour waters?

Coastal/harbour waters can contain corrosive chemicals from pollution and may reduce anode/cooler life.

Effects of corrosion or erosion are specifically excluded from warranty considerations.

Sign off on the zinc anode check

Operate the safety valve manually to verify that the valve mechanism is functioning correctly and that a small amount of air is released.

Check all hoses for signs of deterioration, cracks, hardening etc.

Replace all hoses every 4 years.

Sign off on the air compressor check

Warning: Only trained personnel should perform this procedure.

Position a suitable container under the drain plug.

Was the coolant drained completely?

Remove additional coolant from the airend discharge tube and oil coolers from their respective plugs.

Was the additional coolant removed?

Was the coolant filter replaced?

Was the separator element replaced?

Check the cooler(s) for build up of foreign matter

Cleaned the cooler(s) if necessary?

On water cooled and sea water cooled models, check the water input line strainer for build up of foreign matter

Cleaned the water input line strainer if necessary?
