Ingersoll Rand Air Compressor R110IU-100

Check the cooler(s) for build up of foreign matter

Cleaned the cooler(s) if necessary?

On water cooled and sea water cooled models, check the water input line strainer for build up of foreign matter

Cleaned the water input line strainer if necessary?

Operate the safety valve manually to verify that the valve mechanism is functioning correctly and that a small amount of air is released.

Check all hoses for signs of deterioration, cracks, hardening etc.

Replace all hoses every 4 years.

Sign off on the air compressor check

Warning: Only trained personnel should perform this procedure.

Position a suitable container under the drain plug.

Drain plug positioned correctly?

Remove the plug and completely drain the coolant.

Additional coolant should be removed from the airend discharge tube and oil coolers from their respective plugs.

Warning: Ensure the compressor is turned off and cooled down before starting the procedure

Loosen filter element with the correct tool

Remove the element from the housing

Place the old element in a sealed bag and dispose of in a safe way

Clean the mating face of the housing

Remove the new Ingersoll Rand replacement element from its protective package

Apply a small amount of lubricant to the element seal

Screw the new element down until the seal makes contact with the housing, then hand tighten a further half turn

Start the compressor and check for leaks

Loosen filter element with the correct tool

Remove the element from the housing

Place the old element in a sealed bag and dispose of in a safe way

Clean the mating face of the housing

Remove the new Ingersoll Rand replacement element from its protective package

Apply a small amount of lubricant to the element seal

Screw the new element down until the seal makes contact with the housing, then hand tighten a further half turn

Start the compressor and check for leaks

Sign off on the coolant filter replacement
