Hyster-Yale Forklift S45XM
Need answers fast?
Explore the manual using AI.
The Hyster-Yale Forklift S45XM is a robust industrial forklift designed for heavy-duty applications. Known for its reliability and efficiency, this model excels in material handling tasks, making it an essential asset for warehouses and manufacturing facilities. Optimize your operations with the S45XM's advanced features and durable construction.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for Hyster-Yale Forklift S45XM
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Hyster-Yale Forklift S45XM
Create an account to install this asset package.
Maintenance Plans for Hyster-Yale Forklift Model S45XM
Integrate maintenance plans directly into your work orders in MaintainX.
1000 Hourly / 6 Monthly Forklift Maintenance
Clean or replace diesel fuel filter
Clean or replace Prefilter diesel water separator
Change GM 3.0L EPA Compliant engine cooling system
Lubricate steering axle
Lubricate pedals, levers, seat rails, cables, hinges, linkages, hood latch
Check differential oil powershift transmission
Change PCV valve
Check Perkins 704-26 (UB) breather assembly
Check Perkins 704-26 (UB) breather hose perkins
250 Hourly / 6 Weekly Engine Speed Check
Check Engine Speed Idle Speed Mazda M4-2.0G (Gasoline)
Check Engine Speed Idle Speed Mazda M4-2.2G (Gasoline)
Check Engine Speed Idle Speed Mazda M4-2.0G (IMPCO)
Check Engine Speed Idle Speed Mazda M4-2.0G/M4-2.2G (Asian Closed Loop)
Check Engine Speed Idle Speed Mazda M4-2.0G/M4-2.2G (Asian Open Loop)
Check Engine Speed Idle Speed GM 3.0L (Gasoline)
Check Engine Speed Idle Speed GM 3.0L LPG (IMPCO)
Check Engine Speed Idle Speed GM 3.0L (Asian Closed Loop)
Check Engine Speed Idle Speed GM 3.0L (Asian Open Loop)
1000 Hourly / 6 Monthly Engine Timing Adjustment
Adjust Mazda M4-2.0G Gasoline timing
Adjust Mazda M4-2.0G LPG timing
Adjust Mazda M4-2.2G Gasoline timing
Adjust Mazda M4-2.2G LPG timing
Adjust Mazda GM3.0L timing
Adjust Mazda Perkins 704-26 (UB) timing;
8 Hourly / 1 Daily Forklift Check
Hours meter reading
Date
Signature of Person completing Inspection
Tires condition
Tire pressure
Mast, carriage, lift chains condition
Forks condition
Horn, gauges, lights and alarms operation
Service brakes operation
250 Hourly / 6 Weekly Forklift Maintenance
Check forks condition
Check transmission oil level
Change engine oil filter
Check brake fluid level
Check hydraulic oil level
Clean debris from radiator core
Check air filter
Check battery electrolyte level
Clean battery case and cables
Parts for Hyster-Yale Forklift S45XM
Access the parts list for your equipment in MaintainX.
6 oz Primer T - Aerosol
226415
50 ml Purple Small Screw Threadlock
360387
Silicon Spray
328388
50 ml Red High Viscosity Threadlock
318996
50 ml Green Low Viscosity Threadlock
251099
6 oz Primer T - Aerosol
226415
50 ml Purple Small Screw Threadlock
360387
Silicon Spray
328388
50 ml Red High Viscosity Threadlock
318996
50 ml Green Low Viscosity Threadlock
251099
6 oz Primer T - Aerosol
226415
50 ml Purple Small Screw Threadlock
360387
Silicon Spray
328388
50 ml Red High Viscosity Threadlock
318996
50 ml Green Low Viscosity Threadlock
251099
