The Hyster-Yale H70XL is a robust industrial forklift designed for heavy-duty applications. Known for its reliability and performance, this model excels in material handling tasks, making it an essential asset in warehouses and manufacturing facilities. Optimize your operations with the H70XL's advanced features and durable construction.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Hyster-Yale Forklift H70XL
Create an account to install this asset package.
Maintenance Plans for Hyster-Yale Forklift Model H70XL
Integrate maintenance plans directly into your work orders in MaintainX.
350 Hourly / 2 Monthly Forklift Maintenance
- Replace Diesel Engine oil
- Clean debris from radiator core
- Check condition and operation of the mast, carriage and lift chains
- Check forks condition
- Check condition of the lift chains
- Clean or replace hydraulic tank breather
- Clean or replace air filter. NOTE! Very dirty conditions require daily check and cleaning
- Check brake fluid
- Adjust clutch, brake and inching /brake pedals as required
6 Weekly / 250 Hourly Mast Lubrication
Lubricate pivots
Lubricate Sliding Surfaces and Load Roller Surfaces
Lubricate Sideshift carriage
Lubricate Fork guides
Sign off on the lubrication process
350 Hourly / 2 Monthly Engine Adjustment
- Adjust Engine idle speed GM V-6 from 625 to 675 rpm
- Adjust Engine idle speed (diesel) GM V-6 from 725 to 775 rpm
- Adjust Engine governed speed GM V-6 from 2400 to 2500 rpm
- Adjust Engine governed speed (diesel) GM V-6 from 2400 to 2500 rpm;
8 Hourly / 1 Daily Forklift Check
Check Hydraulic Oil Level
Check engine oil level
Check diesel engine oil PERKINS 4.2482 level
Check diesel engine oil PERKINS 1004-42 level
Check diesel engine oil PERKINS 1104C-44 level
Check powershift transmission oil level
Check oil clutch system oil level
Check fuel tank level
Check the cooling system
500 Hourly / 3 Monthly Forklift Maintenance
Diesel Engine Maintenance (Perkins 1004-42, Perkins 1104C-44)
Diesel engine oil replaced?
Diesel engine oil filter replaced?
Crankcase breather for diesel engine checked?
Sign off on the forklift maintenance
Parts for Hyster-Yale Forklift H70XL
Access the parts list for your equipment in MaintainX.
Silicon Spray
328388
Universal Premium Hydraulic Oil
336831
Silicon Spray
328388
Universal Premium Hydraulic Oil
336831
Silicon Spray
328388
Universal Premium Hydraulic Oil
336831
