Hyster-Yale Forklift H110XL

Replace final diesel fuel filter

Check manual transmission, speed reducer and differential oil

Check single speed powershift transmission

Replace primary diesel fuel filter

- Adjust Engine idle speed GM V-6 from 625 to 675 rpm

- Adjust Engine idle speed (diesel) GM V-6 from 725 to 775 rpm

- Adjust Engine governed speed GM V-6 from 2400 to 2500 rpm

- Adjust Engine governed speed (diesel) GM V-6 from 2400 to 2500 rpm;

Clean and inspect service brakes

Inspect engine vacuum, fuel lines and fittings

Inspect lock off for leaks and ensure lock off closing

Test LPG/gas regulator pressure

Check indicator light of oxygen sensor

Inspect low pressure regulator for oil buildup and leaks

Check air induction system for leaks

Check manifold for vacuum leaks

Check throttle shaft for sticking

Debris cleaned from radiator core

Condition and operation of the mast, carriage and lift chains checked

Condition of the lift chains checked

Hydraulic tank breather cleaned or replaced

NOTE! Very dirty conditions require daily check and cleaning

Hydraulic system oil filter replaced

Oil clutch system oil filter replaced

Sign off on the filter replacement
