Hyster-Yale Chain Hoist 5,0t/2

Warning: This inspection requires trained personnel with PPE!

Supporting structure has sufficient stability

Measure the force absorbed by the supporting structure

Describe any additional loading observed

Sign off on the attachment point inspection

Warning: This procedure requires trained personnel with PPE!

Upload a photo of the open load chain link

Is the length of the cut section at least equal to the thickness of the link?

Is the old hand chain opened on the connection link?

Is the open link suspended into the loose end of the hand chain?

Is the new hand chain also suspended in the open link?

Is the new hand chain pulled through the chain guides and over the hand chain wheel?

Warning: This procedure requires trained personnel!

Lift, pull or tension and lower or release a load over a short distance with the unit

When the hand chain is released, the load must be held in any position

Repeat the check at least twice

Is the brake functioning properly?

ATTENTION: If the brake does not function properly, the unit must be immediately taken out of service and the manufacturer must be contacted!

Sign off on the brake function check

Warning: Ensure the chain is in no-load condition before lubrication

Chain lubricated with creep-type lubricant or PTFE spray

Lubricant reached the contact points of the chain links

Chain lubricated over its entire length, including the part in the hoist housing

Chain cleaned with petroleum or a similar cleaning agent

Chain checked for wear during lubrication

ATTENTION: Ensure no lubricant penetrates into the brake enclosure

Sign off on the load chain maintenance

Warning: Only authorized personnel should perform this procedure

Visible damage or deformations on the load chain?

If damage or deformations are visible, proceed with the replacement. Otherwise, stop the procedure.

Is the replacement chain of the same dimensions and quality?

Is the replacement chain approved by the manufacturer?

Non-compliance with the specifications will render the warranty or guarantee void.

Upload a photo of the new chain

Sign off on the load chain replacement

Document the replacement of the load chain
