The Hussmann Upright Back Bar Deli Case RBB-6-R is an essential refrigeration solution designed for commercial use. This model offers efficient temperature control and optimal visibility for displaying deli products, ensuring freshness and accessibility for customers. Perfect for bars and restaurants, it combines functionality with sleek design.

Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for Hussmann UPRIGHT BACK BAR DELI CASE RBB-6-R

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents & Manuals

Find all the essential guides in one place.

Tensioning Guide
Belt-diagram
C-120 pulleys
+ 13 more

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

Daily Electrical System Inspection
Replace Roller and Pulley
Install Engine B-120
+ 29 more

Procedures

Integrate maintenance plans directly into your work orders.

Motion Industries
Applied Industrial Technologies
Electrical Brothers
+ 5 more

Parts

Access the parts list for your equipment in MaintainX.

Drive Motor
B2 Rollers
Tensioning System
+ 40 more

Hussmann UPRIGHT BACK BAR DELI CASE RBB-6-R

Create an account to install this asset package.

Maintenance Plans for Hussmann UPRIGHT BACK BAR DELI CASE Model RBB-6-R

Integrate maintenance plans directly into your work orders in MaintainX.

Upright Back Bar Deli Case Cleaning

Warning: Shut off fan during cleaning process

Is the fan shut off?

Case Cleaning

Interior bottom cleaned with soap or detergent based cleaners

Sanitizing solution used according to Hussmann’s directions

All surfaces scrubbed thoroughly with soap and hot water

Rinsed with hot water, but not flooded

Sanitizing solution applied

Rinsed thoroughly

Run this procedure

Refrigeration System Maintenance

DANGER! BEFORE SERVICING ALWAYS DISCONNECT ELECTRICAL POWER AT THE MAIN DISCONNECT. WHEN SERVICING OR REPLACING ANY ELECTRICAL COMPONENT.

* This includes (but not limited to) Fans, Heaters Thermostats, and Lights.

1. Evaporator Fans

• The evaporator fans are located at the center front of these merchandisers directly beneath the display pans. Should fans or blades need servicing, always replace fan blades with the raised embossed side of the blade TOWARD THE MOTOR.

2. Coil Access

• The access panel to the coil is through the back wall.

• Remove shelves and unscrew the panel.

• The coil can be accessed through the storage area.

3. Compressor Access

Run this procedure

Stainless Steel Cleaning and Care

Things that can break down your stainless steel’s passivity layer and allow corrosion

1. Mechanical Abrasion

List of tools used that can cause Mechanical Abrasion

2. Water

Describe the quality of water used

3. Chlorides

List of sources of Chlorides

Steps to prevent stainless steel rust

1. Use the Proper Tools

Run this procedure

Plexiglass and Acrylic Maintenance

1. Cleaning

• Clean with plenty of nonabrasive soap (or detergent) and luke warm water, using the bare hand to feel and dislodge any caked-on dirt.

• A soft, grit-free cloth, sponge or chamois may be used, but only as a means of carrying the water to the plastic.

• Dry with a clean damp chamois or clean soft cloth such as cotton flannel. Hard, rough cloths or paper towels will scratch the acrylic and should not be used.

NOTE: The base channel insert must slide out in order to be cleaned. A hose can be used for cleaning purposes of this base insert channel only when no end panel is provided on the case.

2. Waxing

• If after removing dirt and grease, the acrylic can be waxed with a good grade commercial wax.

• This will improve the appearance of the surface by filling in most minor scratches.

• Wax should be applied in a thin even coat and brought to a high polish by rubbing lightly with a dry clean soft cloth, such as a cotton flannel.

Run this procedure
