Hussmann UPRIGHT BACK BAR DELI CASE RBB-4-R

DANGER! BEFORE SERVICING ALWAYS DISCONNECT ELECTRICAL POWER AT THE MAIN DISCONNECT. WHEN SERVICING OR REPLACING ANY ELECTRICAL COMPONENT.

* This includes (but not limited to) Fans, Heaters Thermostats, and Lights.

• The evaporator fans are located at the center front of these merchandisers directly beneath the display pans. Should fans or blades need servicing, always replace fan blades with the raised embossed side of the blade TOWARD THE MOTOR.

• The access panel to the coil is through the back wall.

• Remove shelves and unscrew the panel.

• The coil can be accessed through the storage area.

• Clean with plenty of nonabrasive soap (or detergent) and luke warm water, using the bare hand to feel and dislodge any caked-on dirt.

• A soft, grit-free cloth, sponge or chamois may be used, but only as a means of carrying the water to the plastic.

• Dry with a clean damp chamois or clean soft cloth such as cotton flannel. Hard, rough cloths or paper towels will scratch the acrylic and should not be used.

NOTE: The base channel insert must slide out in order to be cleaned. A hose can be used for cleaning purposes of this base insert channel only when no end panel is provided on the case.

• If after removing dirt and grease, the acrylic can be waxed with a good grade commercial wax.

• This will improve the appearance of the surface by filling in most minor scratches.

• Wax should be applied in a thin even coat and brought to a high polish by rubbing lightly with a dry clean soft cloth, such as a cotton flannel.

Things that can break down your stainless steel’s passivity layer and allow corrosion

List of tools used that can cause Mechanical Abrasion

Describe the quality of water used

Steps to prevent stainless steel rust

• Long life and satisfactory performance of any equipment are dependent upon the care given to it. To insure long life, proper sanitation and minimum maintenance costs, the refrigerator should be thoroughly cleaned frequently. SHUT OFF FAN DURING CLEANING PROCESS.

• It can be unplugged within the case, or shut off entire case at the source. The interior bottom may be cleaned with any domestic soap or detergent based cleaners. Sanitizing solutions will not harm the interior bottom, however, these solutions should always be used according to the Hussmann’s directions. It is essential to establish and regulate cleaning procedures. This will minimize bacteria causing discoloration which leads to degraded product appearance and significantly shortening product shelf life.

• Soap and hot water are not enough to kill this bacteria. A sanitizing solution must be included with each cleaning process to eliminate this bacteria.

1. Scrub thoroughly, cleaning all surfaces, with soap and hot water.

2. Rinse with hot water, but do not flood.

3. Apply the sanitizing solution according to Hussmann’s directions.

5. Dry completely before resuming operation.
