Hussmann Q-Series Medium Temperature Self Contained Merchandiser Q2SSM8S

CAUTION! DO NOT FLOOD! Use only enough water necessary to clean surface. Water must not drip down the case! Never use ammonia based cleansers, abrasive cleansers, or scouring pads.

Used non-abrasive cleaning materials and polished with grain of the steel

Used warm water or added a mild detergent to the water and applied with a cloth

Used alkaline chlorinated or non-chlorine containing cleaners such as window cleaners and mild detergents

Did not use cleaners containing salts as this may cause pitting and rusting of the stainless steel finish

Sign off on the stainless steel surfaces cleaning

Long life and satisfactory performance of any equipment is dependent upon the care it receives. To ensure long life, proper sanitation and minimum maintenance costs, these merchandisers should be thoroughly cleaned, all debris removed and the interiors washed down, weekly.

Exterior surfaces cleaned with a mild detergent and warm water

Interior surfaces cleaned with appropriate cleaners

Check if any of the following were used

WARNING! Product will be degraded and may spoil if allowed to sit in a non-refrigerated area.

Warning: Always wear gloves and protective eye wear when cleaning near sharp coil fins and dust particles.

Check if condenser coils are clean

If coils are dirty, proceed to next step

Clean the coils using a vacuum cleaner with a wand attachment and a soft (non-metallic) brush

Check if the coils are clean after cleaning

CAUTION! Evaporation Pan is Hot! and poses risk of bodily injury – Always Wear gloves and protective eye wear when servicing. Turn off evaporation pan heater, and allow pan to cool.

Evaporation pan heater turned off and allowed to cool?

The condensate water outlet for self contained models empties into a limited capacity evaporation pan.

Debris or dirt accumulation inside the condensate evaporation pan or on the heater coil will reduce the pan’s evaporation capacity and cause premature heater failure. The evaporation pan waste water will overflow and spill onto the floor if the heater is not properly operating.

Remove accumulated debris from the evaporation pan.

Wipe down heater coil with a cloth and warm water.

Remove any dirt, debris or liquids from the heater coil.

Water introduced during cleaning will cause the evaporation pan to overflow.

Warning: Be careful not to damage the louvers during cleaning

Select the cleaning method used

Is all water removed from the louvers cells before replacing?

Upload a photo of the cleaned louvers

Sign off on the louver cleaning
