Graco Airless Sprayer Ultimate Mx II 695 Standard

Drive housing (89) removed without dropping gear cluster (89)

Four screws (38) and control cover (96) removed

Bottom two screws (39) removed and control panel (68) hanging freely

All three motor leads disconnected from motor control board (95)

Top two screws (39) and control housing (61) removed

Strain relief (29) removed from motor wires and power bar plate (69)

3. Fig. 6. Remove screw (31) and slide pump rod shield (108) forward.

4. Fig. 8. Cycle pump in JOG mode until pump pin (44) is in position to be removed. Turn power switch OFF and unplug power cord. Push up retaining ring (43) and push pump pin out.

5. Fig. 7. Remove suction tube (76), hose (94) and any washers and o-rings.

6. Loosen pump jam nut (56). Unscrew pump.

2. Fig. 3. Remove four screws (38) and cover (96).

3. Disconnect display connector (A) from motor control board (95).

4. Remove bottom two screws (39) and allow control panel (68) to hang down freely.

5. Disconnect control board power lead(s) (D) from ON/OFF switch (33) and motor control board (95).

6. Disconnect potentiometer connector (C) from motor control board.

7. Disconnect 15/20A switch (178) (1595).

Do not drop gear cluster (89) when removing drive housing (90). Gear cluster may stay engaged in motor front end bell or drive housing.

2. Remove screw (31), two nuts (24), pail hanger (55) and pump rod cover (108).

3. Remove pump (91); Displacement Pump Replacement, page 16.

4. Fig. 4. Remove two screws (31) and shroud (72).

5. Remove four screws (31) and front cover (51).

6. Remove four screws (14) and washers (12) to remove bearing housing (83) and connecting rod (85).
