Getinge Steam Sterilizer 522LS

Ensure the Installation Checklist is completed by a Getinge representative or its agent

Equipment Inspection and Evaluation

Run qualifying tests to inspect and evaluate the equipment

Is the equipment operating to specification?

Schedule an in-service review with the customer's Getinge sales representative

Has the in-service review been completed?

Release the equipment to the customer for use

CAUTION — POSSIBILITY OF DAMAGE TO EQUIPMENT

Check the torque of the three-phase supply terminals

Check the torque of the contactor terminals

Check the torque of the heating element terminals

Check the torque of the heating element flange bolts

See Figure 5–7 for the GTS-30A Steam Boiler

See Figure 5–8 on page 5–9 for the CAS-30C and the SSB30C Steam Boiler

Check that utilities are connected properly and piping and wiring comply with all applicable codes

Check that the sterilizer is anchored to the floor and seismic anchoring (if required) complies with all applicable codes

Check that the panels are installed and secure
