Gardner Denver Base Mounted Compressor L110W

Warning! Danger when cleaning system parts with compressed air: Small parts propelled at high speed by compressed air can penetrate the skin or destroy an eye.

Do not aim the compressed air at people

Caution! Fire hazard from oil residues. Oil residue and other deposits must be removed from the compressor coolers which are exposed to hot air in accordance with the user manual.

Dirt trap strainer removed and cleaned? (only for water-cooled units)

High voltage – Hazard of shock, burn, or death

 Be careful with electricity: only work on screw compressors which are not powered.

 Only for L90RS-L132RS: There is a risk of electric shock from charged capacitors! Disconnect the systemfrom the mains and wait 10 minutes before touching electrical components.

The power capacitors need this time to discharge.

Every 8000 hours operation or 24 months

1. Inspect solenoid valves /vacuum switch operation, replace if necessary.

2. Inspect blow-down valve operation, replace if necessary.

3. Inspect thermistor probes operation, replace if necessary.

Danger! Air/oil under pressure will cause severe personal injury or death.

Shut down the compressor, relieve the system of all pressure, disconnect, lockout and tagout the power supply to the compressor package before removing valves, caps, plugs, fittings, bolts and filters.

Caution! Fire hazard and slip hazard!

Oil residue and other deposits must be removed from the compressor coolers which are exposed to hot air in accordance with the user manual.

Look for leaks! Immediately take care of any spilled oil!

Turn off the screw compressor unit, secure it against accidental restarts and make sure that the demister vessel is depressurized.

Slowly open the oil screw plug to relieve the screw compressor of any residual pressure in the system

Danger: High voltage – Hazard of shock, burn, or death. Be careful with electricity: only work on screw compressors which are not powered.

Only for L90RS-L132RS: There is a risk of electric shock from charged capacitors! Disconnect the system from the mains and wait 10 minutes before touching electrical components.

Warning! Some parts of the system will still be pressurized after the system has been switched off. Small parts propelled at high speed by compressed air can penetrate the skin or destroy an eye.

Caution! Burn hazard – Hot surfaces. Be careful of the hot surfaces of machine parts when carrying out checks, making settings and doing maintenance.

Check air/oil reservoir oil level, add oil if required. DO NOT MIX LUBRICANTS.

Check operation of the machine, is it loading and unloading properly.

Check control panel for advisory text messages.

Warning: Rotating machinery can cause injury or death. Open main disconnect, lockout and tagout power supply to starter before working on the electric motor.

Unit disconnected, locked out and tagged out from the power supply?

Relief plug removed and hole free of hardened grease?

Lubrication fitting wiped clean and grease added with a hand-operated grease gun?

Relief plug left temporarily off?

Unit reconnected and run for about 20 minutes to expel the excess grease?

Unit stopped and relief plug replaced?
