Torque the wheel hub slotted nut to 125 ft-lb (169 N-m)

Was anti-seize compound used on the wheel hub?

Stop engine, wait for all moving parts to stop, and remove key.

Replace the secondary air cleaner element.

Refer to the Engine Owner's Manual for additional maintenance instructions.

Check the wheel hub slotted nut torque specifications.

Stop engine and wait for all moving parts to stop

Remove key and engage parking brake

Ensure engine is warm from operation

Place pan under machine to catch oil

Remove plug from end of drain hose and allow oil to drain

Torque oil drain plug to 20-24 ft-lb

Stop engine, wait for all moving parts to stop, and remove key.

Clean all debris from rotating engine air intake screen.

Clean all debris around engine shrouding.

Clean all debris from exhaust system area.

Wipe up any excessive grease or oil around the engine and exhaust system area.

Stop engine and wait for all moving parts to stop

Check the drive tire pressures and tire circumferences

Run the unit on a level, smooth, hard surface such as concrete or asphalt

Does the unit track straight on the surface?

Adjust the quick track knob to correct tracking
