Daikin Air Handler CAH016GVDM

Check all moving parts for wear

Check bearing collar, sheave, and wheel hub setscrews, sheave capscrews, and bearing hold-down bolts for tightness

Annually check and snug all electrical connections

Inspect for signs of water damage such as corrosion and repair if necessary

Check ground conductor and connection integrity and correct if needed

Adjust motor base forward to release belt tension

Remove the belts for easier adjustment

Loosen, but do not remove both of the locking setscrews A in the outer locking ring by using a hex key or torque wrench with a hex bit

Adjust sheave to desired pitch diameter by turning the outer locking ring, using a spanner wrench or drift inserted into the three holes that are located 120° apart on the ring

Ensure pitch diameter is within the sheave range. One complete turn of the outer locking ring changes the pitch diameter 0.233\" 6"

Tighten BOTH locking screws A in the outer locking ring before operating the drive. Use a torque wrench and tighten to the value

Replace belts and adjust the motor base to tension the belts properly

Do not loosen any screws other than the two locking screws A in the outer locking ring when adjusting the sheave pitch. Do not operate the drive until the locking screws have been set to the torque specifications

Sign off on the MVP Variable Speed Sheave Maintenance

CAUTION: Bearing overheating potential. Can damage the equipment. Do not over lubricate bearings. Use only a high grade mineral grease with a 200°F safe operating temperature.

NOTE: Direct-Drive Class Il fans that are supplied with TECO motors have double shielded bearings on frame sizes 140T-280T. These bearings are pre-packed with a long life grease and are not regreaseable. Larger frame size TECO motors are regreaseable and follow the same lubrication recommendations as all other motors

Select the type of lubricant used

Enter the amount of lubricant used (in oz)

Did you remove and clean upper and lower grease plugs?

Did you insert a grease fitting into the upper hole and add clean grease with a low pressure gun?

Did you run the motor for five minutes before replacing the plugs?

Sign off on the motor bearings lubrication

WARNING: Before servicing fans, lock out and tag out all power to the unit. Fans or belts can cause severe personal injury or death

WARNING: Do not open the hinged access door and screw-fastenerd access panels while the unit is operating. Moving parts and strong suction forces can cause severe personal injury or death

Replace the variable pitched motor sheave with a properly sized, fixed sheave

Replace the adjustable sheaves with fixed sheaves

Measure the diameter of the V-belt outer surface where it passes around the sheave (pitch diameter)

Calculate fan speed from the motor nameplate rpm

Sign off on the fan drive maintenance

Warning: Moving belt and fan can cause severe personal injury or death. Always ensure safety measures are in place.

Is the belt tension at the lowest tension at which the belt does not slip under peak load conditions?

Has the tension been checked frequently during the first 24 to 48 hours of operation?

Are the belts free from foreign material that can cause slippage?

Has the V-drive been inspected on a periodic basis?

Enter the force applied to the belt tension checker

Does the measured force match the required values?

Are the belt and fan guards on plenum fan units always in place?
