Caterpillar Compact Wheel Loader 910M

Change Transfer Drive Oil. Sampling Only

Change Front Differential and Final Drive Oil. Sampling Only

Change Rear Differential and Final Drive Oil. Sampling Only

Change Engine Oil / Filter Element. Enter the amount of oil used in liters

Lubricate Machine with Prime Application Grease

Change Hydraulic Filter Element

Sign off on the 500 Hours Loader Maintenance

Enter the quantity of Hydo Advanced used (in L)

Hydraulic Oil changed successfully?

Hydraulic Tank drained successfully?

Change Brake Fluid (if equipped)

Brake Fluid changed successfully?

Sign off on the 2000 Hours Loader Maintenance

Enter the amount of oil used for Transfer Drive (in L)

Change Front Differential and Final Drive Oil

Enter the amount of oil used for Front Differential (in L)

Enter the amount of oil used for Front Final Drive (in L)

Change Rear Differential and Final Drive Oil

Enter the amount of oil used for Rear Differential (in L)

Enter the amount of oil used for Rear Final Drive (in L)

Sign off on the maintenance procedure

- Change Transfer Drive Oil.3.2 L (0.85 gal). Changed every 1,000 hours after the initial 500 hour change (i.e., 1,500 hours, 2,500 hours, etc.)

- Change Front Differential and Final Drive Oil. Diff = 7.5 L (1.98 gal), Hub = 1.3 L (0.34 gal) each. Changed every 1,000 hours after the initial 500 hour change (i.e., 1,500 hours, 2,500 hours, etc.)

- Change Rear Differential and Final Drive Oil. Diff = 7.5 L (1.98 gal), Hub = 1.3 L (0.34 gal) each. Changed every 1,000 hours after the initial 500 hour change (i.e., 1,500 hours, 2,500 hours, etc.);

- Check DEF Injector every 5000 hours

- Add Engine Coolant Extender 0.4 L (0.11 gal) (depending on S•O•SSM Coolant Sampling Results) every 6000 hours

- Check DEF Manifold Filter Element every 10000 Hours

- Change Engine Collant 21.5 L (5.55 gal) every 12000 Hours;
