Canon Printer MF745Cdw

Create an account to install this asset package.

Maintenance Plans for Canon Printer Model MF745Cdw

Integrate maintenance plans directly into your work orders in MaintainX.

Printer Toner Cartridge Replacement

Preparation

Check toner cartridge status

Is a replacement toner cartridge ready?

Toner Cartridge Replacement

Open the front cover

Pull out the cartridge tray

Remove the target toner cartridge

Unpack the replacement toner cartridge

Shake the toner cartridge 5 or 6 times

Run this procedure

Printer Fixing Assembly Cleaning

Preparation

Ensure there are no documents waiting to be printed

Ensure the following items are ready

Clean Fixing Assembly (Reduce Paper Back Side Stain)

Was the previous printing session completed at least one hour ago?

Select <Menu> in the Home screen

Select <Adjustment/Maintenance> <Maintenance>

Select <Clean Fixing Assembly (Reduce Paper Back Side Stain)>

Is the correct size and type of paper loaded in the machine?

Run this procedure

Printer Feeder Cleaning

Manual Feeder Cleaning

Turn off the machine and unplug it from the power outlet

Open the original supply tray

Open the feeder cover

Wipe the rollers in the feeder

Close the feeder cover and original supply tray

Open the feeder

Wipe the document feed scanning area

Wait for the cleaned area to dry completely

Run this procedure

Printer Exterior Cleaning

Preparation

Turn OFF the machine and unplug the power cord from the AC power outlet.

Cleaning Process

Clean the exterior of the machine and the ventilation slots using a soft, well-wrung-out cloth dampened with water or a mild detergent diluted with water.

Note any visible damage or issues during cleaning.

Post-Cleaning

Wait for the exterior of the machine to dry completely.

Reconnect the power cord and turn ON the machine.

Run this procedure

Printer Platen Glass Cleaning

Turn OFF the machine and unplug the power cord from the AC power outlet

Open the feeder or the platen glass cover

Clean the platen glass and the underside of the feeder or the platen glass cover

Dampen a cloth with water and clean the areas

Wipe the area with a soft, dry cloth

Wait for the cleaned area to dry completely

Gently close the feeder or the platen glass cover

Reconnect the power cord and turn ON the machine

Run this procedure

Parts for Canon Printer MF745Cdw

Access the parts list for your equipment in MaintainX.

Part Name

Part Number

Printer Cartridge, Average Yield 2,300 Sheets, Weight Approx. 4.9 lb (2.2 kg)

Canon Cartridge 055 Black
