Canon Printer MF741Cdw

Create an account to install this asset package.

Maintenance Plans for Canon Printer Model MF741Cdw

Integrate maintenance plans directly into your work orders in MaintainX.

Printer Fixing Assembly Cleaning

Preparation

Ensure there are no documents waiting to be printed

Ensure the following items are ready

Check toner cartridges for sufficient amount remaining

Clean Fixing Assembly (Reduce Paper Back Side Stain)

Has it been at least one hour since the last printing session?

Select <Menu> in the Home screen

Select <Adjustment/Maintenance> <Maintenance>

Select <Clean Fixing Assembly (Reduce Paper Back Side Stain)>

Run this procedure

Printer Transfer Belt Cleaning

Ensure no documents are waiting to be printed

Select <Menu> in the Home screen

Navigate to <Adjustment/Maintenance> <Maintenance>

Select <Clean ITB>

Select <Start> to begin cleaning

Post-Cleaning Steps

Confirm cleaning is complete

Return to the Home screen

Run this procedure

Printer Platen Glass Cleaning

Preparation

Turn OFF the machine and unplug the power cord from the AC power outlet

Note any important data that might be lost when the printer is turned off

Cleaning Process

Open the feeder or the platen glass cover

Clean the platen glass and the underside of the feeder or the platen glass cover

Wait for the cleaned area to dry completely

Finalization

Gently close the feeder or the platen glass cover

Run this procedure

Printer Adjustment

Adjust Print Position for Specific Paper Source

Select <Menu> in the Home screen.

Select <Adjustment/Maintenance> <Adjust Image Quality>.

Select <Adjust Print Position>.

Select the paper source.

Select the combination of adjustment direction and printing side.

Set an adjustment value in mm.

Select <Apply>.

Adjust Print Position for All Print Jobs

Run this procedure

Printer Exterior Cleaning

Preparation

Turn OFF the machine and unplug the power cord from the AC power outlet

Note any data that may be lost when the machine is turned off

Cleaning Process

Clean the exterior of the machine and the ventilation slots

Post-Cleaning

Has the exterior of the machine dried completely?

Reconnect the power cord and turn ON the machine

Run this procedure

Parts for Canon Printer MF741Cdw

Access the parts list for your equipment in MaintainX.

Part Name

Part Number

Printer Cartridge, Average Yield 2,300 Sheets, Weight Approx. 4.9 lb (2.2 kg)

Canon Cartridge 055 Black
