Bakers Pride Gas Deck Oven GS805

Is the timer set to the correct time?

Does the timer turn the main burner on at the set time?

Can the main burner be lit manually by turning the timer switch to 'ON'?

Ignition Module and Hot Surface Ignitor Check

Verify the ignition module energizes the hot surface ignitor when turned on.

Check if the hot surface ignitor reaches the required current to open the gas valve.

Flame Sensor and Burner Operation

Ensure the flame sensor completes the circuit by sensing the flame.

Is the burner flame YELLOW to simulate wood burning?

Booster Burner Location and Visual Inspection

Locate the Il Forno booster burner at the center rear of the oven cavity.

Is the booster burner visible through the front opening?

WARNING: Qualified Service Agency Required

Confirm the qualified service agency details

Remove the two screws holding the regulator in place

Install a new gasket and the new regulator

Ensure the regulator gasket is correctly positioned

Evenly tighten the two screws holding the regulator

Ensure all appliances on the same gas supply line are running at their highest burner setting.

Locate the pressure tap in the control compartment along the gas supply piping.

Connect a manometer to the pressure tap and record the gas pressure while the burners are running at their highest setting.

Does the gas supply pressure match the oven’s rating plate?

Select the type of valve equipped in the oven.

If equipped with a 7000 combination valve, adjust the screw on the front of the valve to match the gas supply.

Set the temperature dial to 300°

Wait for the oven temperature to rise and remain constant, then turn the dial to the lowest setting

Confirm the main valve is closed

Remove the knob by pulling straight from the thermostat body

Adjust the by-pass flame using the upper screw marked 'B' on the left side of the thermostat body

Turn the screw counter-clockwise to increase the flame height

Turn the screw clockwise to reduce the flame height

Ensure the flame is at a minimal height that maintains itself along the burners

Replace the dial and test by turning the temperature up and down several times
