Air Science Laminar Flow Cabinet HLF-24

Ensure the following components are removed before proceeding

Disconnect electrical connections as necessary to free blower

Remove screws and lift up blower assembly from the supply plenum

Remove mounting plate from the 4 aluminum profiles

Remove blower from the mounting plate

Reinstall blower by reversing removal steps

Ensure the following components are removed

Disconnect electrical connections as necessary to free blower

Remove nuts clamping the blower

Carefully pull out and lift up blower

Reinstall blower by reversing removal steps

Clean the exterior surfaces of the cabinet with a damp cloth

Use soap or mild detergent if necessary

Check all service fixtures for proper operation

Select suitable disinfecting agents for stainless steel

Select suitable disinfecting agents for powder coated surfaces

Spray chemicals onto a wipe or cloth before applying to surfaces

Avoid spraying cleaning agents onto acrylic panels

Ensure no chlorine-based substances are used on steel and stainless steel surfaces

Recertification by qualified technician

Perform all semiannual activities
