Mitsubishi Split-Type, Heat Pump Air Conditioner PKFY-P63VKM-ER1.TH

Remove 2 screws of the vane motor unit cover, and pull out the vane motor unit

Remove 2 screws of the vane motor unit

Remove the vane motor from the vane motor unit

Disconnect the connector from the vane motor

Remove the panel and the corner box

Remove the screw and hook of address board case

Remove the front and side electrical box covers (each 1 screw)

Remove the transmission wiring of TB5, the power supply wiring of TB2 and the wiring of MA-remote controller (TB15)

Disconnect the connectors on the indoor controller board

Disconnect the connector for ground wire

Remove the screw on lower side of the electrical box

Push up the upper fixture catch to remove the box, then remove it from the box fixture

Remove the panel and corner box

Remove the electrical box covers

Disconnect the vane motor connector (CN151) on the indoor controller board

Pull out the drain hose from the nozzle assembly, and remove nozzle assembly

Upload a photo of the disassembled nozzle assembly and drain hose

Remove the panel and corner box

Remove the electrical box covers

Remove the room temperature thermistor

Disconnect the connector (CN20) on the indoor controller board

Remove the panel and the corner box

Remove the screw and hook of address board case

Disconnect the connectors of address board

Remove the front and side electrical box covers (each 1 screw)

Disconnect the connectors on the indoor controller board

Remove the switch board holder and open the cover

Pull out the indoor controller board toward you then remove the indoor controller board and switch board

Remove the holder of wireless remote controller board

Disconnect the connector of wireless remote controller board and remove the wireless remote controller board from the holder
