Miller Arc Welding Power Source Wire Feeder Multimatic 215

Remove guide by pressing on barbed area or cutting off one end near housing and pulling it out of hole.

Push new guide into hole from rear until it snaps in place.

The drive roll includes three different sized grooves. The text aligned with the drive roll retaining pin indicates the selected groove.

To secure drive roll, locate open slot and push drive roll completely over retaining pin, then rotate drive roll to desired slot.

Sign off on the replacement procedure

Caution: Disconnect power before maintaining.

Upload a photo of the weld cable

Warning: Only trained personnel should perform this procedure

Check if the CB1 supplementary protector is open

If CB1 is open, the unit will shut down

If the unit shut down, reset the supplementary protector

Caution: Disconnect power before maintaining.

Sign off on the cleaning procedure
