Magic Aire Fan Coil Unit 120BRX
Create an account to install this asset package.
Maintenance Plans for Magic Aire Fan Coil Unit Model 120BRX
Integrate maintenance plans directly into your work orders in MaintainX.
Water Piping Maintenance
CAUTION: Never operate unit without a filter or with filter access door removed. Damage to blower motor may result.
Water Piping Maintenance Steps
Remove unit access panel, filter access door, and filter
Clean the drain coil using accepted industry methods
Remove all foreign matter from pan and condensate drain line
Inspect for rust and holes
Motor Maintenance
Lubrication
Use electric motor oil or SAE20 nondetergent oil
Ensure not to over-oil
Motor Mount Inspection
Tighten motor mount bracket
Tighten base bolts as required
Screws And Bolts Check
Belt and Pulley Inspection
Check pulley alignment
Check belt tension
Pulley Adjustment
Is the pulley speed set correctly?
Adjust pulley speed
Screws and Bolts Check
Check that all the screws and bolts are in place and secure
Blower Maintenance
Bearing Inspection and Replacement
Check bearing for wear
Replace bearing if required
Wheel Maintenance
Check wheel for accumulation of dirt
Clean wheel if required
1 Monthly Air Filter Maintenance
WARNING: Disconnect electrical power to all circuits before servicing unit.
Ensure electrical power is disconnected to all circuits
Return Air Filters Maintenance
Access filter from either side of unit
Inspect the air filter for dirt and debris
Action required for air filter
