The John Deere Tractor 5403 is a robust agricultural machine designed for efficiency and reliability. Known for its powerful performance, this tractor is ideal for various farming tasks, ensuring optimal productivity in the field. With regular maintenance, the 5403 can deliver exceptional service for years to come.

Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for John Deere Tractor 5403

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents & Manuals

Find all the essential guides in one place.

Tensioning Guide
Belt-diagram
C-120 pulleys
+ 13 more

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

Daily Electrical System Inspection
Replace Roller and Pulley
Install Engine B-120
+ 29 more

Procedures

Integrate maintenance plans directly into your work orders.

Motion Industries
Applied Industrial Technologies
Electrical Brothers
+ 5 more

Parts

Access the parts list for your equipment in MaintainX.

Drive Motor
B2 Rollers
Tensioning System
+ 40 more

John Deere Tractor 5403

Create an account to install this asset package.

Maintenance Plans for John Deere Tractor Model 5403

Integrate maintenance plans directly into your work orders in MaintainX.

1000 Hourly Maintenance

Lower rockshaft to remove trapped oil

Remove drain plug (A) from transmission case and drain out oil

Dispose of waste oil properly

If equipped with MFWD axle, also remove drain plug (B) in drop housing

Replace filter (B) while changing oil

Apply a film of oil to new filter gasket and install new filter. Hand tighten only

Fill system with transmission-hydraulic oil

Check oil level at dipstick (D) after filling, and again after operating for five minutes

Drain transmission-hydraulic oil for cleaning transmission-hydraulic pickup screen

Run this procedure

100 Hourly Maintenance

Change engine oil and filter

Run engine to heat oil

Remove oil drain plug (A) and drain oil

Replace engine oil filter (B) while changing oil. Apply a film of oil on the new oil filter gasket and install new filter. Hand tighten plus 1/2 turn

Install drain plug

Add seasonal viscosity grade oil. (See Fuels, Lubricants and Coolant section.)

Replace transmission-hydraulic filter

Remove filter (A). Apply a film of oil to new gasket and install new filter. Hand tighten plus 1/2 turn

Run engine several seconds and recheck transmission-hydraulic oil level

Run this procedure

100 Hourly Maintenance

Replace transmission-hydraulic filter element

Remove filter (A). Apply a film of oil to new gasket and install new filter. Hand tighten plus 1/2 turn.

Run engine several seconds and recheck transmissionhydraulic oil level.

Add transmission fluid if required (See Fuels, Lubricants and Coolant section).

Change engine oil and filter

Run engine to heat oil.

Remove oil drain plug (A) and drain oil.

Replace engine oil filter (B) while changing oil. Apply a film of oil on the new oil filter gasket and install new filter. Hand tighten plus 1/2 turn.

Install drain plug.

Run this procedure

100 Hourly Maintenance

Replace transmission-hydraulic filter

Remove filter (A). Apply a film of oil to new gasket and install new filter. Hand tighten plus 1/2 turn.

Run engine several seconds and recheck transmissionhydraulic oil level.

Add transmission fluid if required (See Fuels, Lubricants and Coolant section).

Change engine oil and filter

Run engine to heat oil.

Remove oil drain plug (A) and drain oil.

Replace engine oil filter (B) while changing oil. Apply a film of oil on the new oil filter gasket and install new filter. Hand tighten plus 1/2 turn.

Install drain plug.

Run this procedure

10 Hourly Maintenance

Park tractor on level ground

Check engine oil level

DO NOT operate engine when oil level is below low mark on dipstick.

If level is low, add oil through oil filler hole until even with upper mark. DO NOT over fill.

Check coolant level in coolant tank

If engine is cool and level is below 'LOW' add coolant to recovery tank to bring to 'LOW'.

Drain water and sediment from fuel tank

Drain water and sediment from fuel filter

Lubricate tie rod ends
