Carrier Outdoor Unit Single Zone Ductless System 38MARBQ36AA3
Create an account to install this asset package.
Maintenance Plans for Carrier Outdoor Unit Single Zone Ductless System Model 38MARBQ36AA3
Integrate maintenance plans directly into your work orders in MaintainX.
EXV Check
WARNING: ELECTRICAL SHOCK HAZARD. Electricity remains in the capacitors even when the power is off. Ensure the capacitors are fully discharged before troubleshooting.
Disconnect the connector from the outdoor PCB.
Measure the resistance value of each winding using a multi-meter.
Check the resistance value of each winding
Sign off on the EXV Check
Compressor Check
Disconnect the compressor power cord from the outdoor PCB
Measure the resistance valve of each winding using a multi-meter
Check the resistance valve of each winding in Tables 21 - 21
IPM Continuity Check
WARNING: ELECTRICAL SHOCK HAZARD. Electricity remains in the capacitors even when the power is off. Ensure the capacitors are fully discharged before troubleshooting.
Outdoor unit turned off and power supply disconnected
Electrolytic capacitors fully discharged
Outdoor PCB or IPM board disassembled
Measure the resistance valve between P and U(V,W,N)
Measure the resistance valve between U(V,W) and N
Sign off on the IPM Continuity Check
Main Parts Check
Temperature sensor checking
Disconnect the temperature sensor from PCB
Measure the resistance value with a tester
Temperature sensors
Measure the resistance value of each winding by using the multi-meter
Sign off on the parts check
Temperature Sensor Check
WARNING: Be sure to turn off all power supplies or disconnect all wires to avoid shock. Operate after the compressor and coil have returned to a normal temperature in case of injury.
Temperature sensor disconnected from PCB
Sensor’s resistance value
Upload a photo of the multi-meter reading
Check the corresponding temperature sensor’s resistance value table
Sign off on the temperature sensor check
