Bunn Dispenser 37000.0000

Warning: Do NOT clean this equipment with a water jet device

The cleaning instructions noted are for non-dairy sugar based food products. When dispensing any other food product, the cleaning cycle for the whipping chamber assembly and ejector elbow must be performed daily

Clean the dispenser with a damp cloth rinsed in any mild, non-abrasive, liquid detergent

Rinse out Whipper Chambers by placing RINSE/RUN switch in the 'RINSE' position and activating DISPENSE switches

Turn elbow up, remove Hoppers, refill with product and replace hoppers into dispenser

Empty Drip Tray and wash in a solution of dish detergent

Sign off on the dispenser cleaning

Warning: This procedure requires trained personnel!

Is the dispenser equipped with sensors to detect a low level in each hopper?

Is the LCD screen on the door displaying a low level condition?

Is the 'NORMAL/PROGRAM/RINSE' switch in the 'PROGRAM' position?

Did you press button A below the BUNN logo on the front of the door until the 'LOCKS/DISABLES?' menu is reached?

Did you press button B for 'YES', then press it again in the 'LOW POWDER LOCK?' menu?

Did you press button C to exit the program menus, then return the 'NORMAL/PROGRAM/RINSE' button to the 'NORMAL' position?

Is the hopper at least half full of product for calibration?

Did you place the 'NORMAL/PROGRAM/RINSE' switch in the 'PROGRAM' position?

CAUTION - The dispenser must be disconnected from the power source throughout these steps

Disconnect the dispenser from the power source

Open front door and place ON/OFF/NIGHT switch in the 'OFF' (center) position and let the water in the tank cool before draining

Shut off and disconnect the incoming water supply

Remove the drip tray and access panels below the door

Pull the clamped end of the silicone tube out of the dispenser and direct it into a drain or a container large enough to hold the volume of water in the tank (7.3 gal for iMIX-4/5 and 4.4 gal for iMIX-3)

Make certain the shut off clamp is locked tightly on the tube, then remove the snap type clamp and plug from end of tube

Carefully release the shut off clamp to let the water drain from the tank

NOTE - The dispenser must be refilled using the INITIAL FILL & HEAT steps before reconnecting to the power source

Replace cycle of Mixing Chamber Kit is 6 months

Replace cycle of Whipper Shaft Seal Kit is 3 months or as needed

Sign off on the dispenser cleaning
