Bunn Brewer SURE IMMERSION 312

If you are starting with a new paper roll, start here

If you are continuing with a partial roll that you cut at the top spindle, go to step 2

Install filter paper roll and then route the filter paper through the tractor drive as shown

Pull the end of the paper roll up, and over left spindle

Pull end of paper between the Brew Funnel and Brew Box

Continue paper over the top spindle, then on the left side of the middle spindle. Feed the paper in front of the pick-up (bottom) spindle with the handle

Flip the handle a quarter turn to the left

Remove and wash the drip tray and drip tray cover in a mild detergent solution. Rinse thoroughly

Wipe the lower front panel, door, and cabinet with a clean damp cloth

Selecting the RINSE tab from the CARE AND CLEANING screen will prepare the equipment for rinsing the Brew Funnel and Brew Box

Follow the directions shown on the screen

Once the START button has been pressed, the CARE AND CLEANING screen will show a progress bar - with the message 'Please Wait - Rinsing'

If for any reason the rinsing process needs to be halted, press the Stop button

Warning: Do not use any abrasive materials for cleaning.

Cleaned the exterior surfaces with a damp cloth rinsed in mild, non-abrasive, liquid detergent?

Wiped down the exterior surfaces of the dispenser with a soft, dry cloth to maintain the luster of the finish?

Washed the stainless steel interior surfaces of the dispenser with warm, soapy water and rinsed with warm, clear water?

If the water is hard, did you wipe the dispenser using a dry soft cloth, to prevent spotting?

Sign off on the Brewer General Cleaning

Warning: Ensure the machine is turned off before starting the cleaning process

The touch panel is deactivated for 15 seconds for cleaning

Clean the touch panel during the countdown

Machine resets and returns to the main selection screen

Sign off on the touch panel cleaning

Remove the powder mixing chambers, steam traps, frothers and mixing chamber bases

Remove the dispense hoses from the dispense nozzle assembly

Clean all parts removed in warm soapy water. Use the provided cleaning brush (PN 26367.0000) to clean bores and orifices. Rinse in cold water

Prepare one-gallon (3.8 liter) of sanitizing solution with at least 100 ppm of available chlorine in 120°F (48.9°C) water. Soak all cleaned parts in sanitizing solution for 5 minutes, then allow to air dry

Rinse cleaning brush, dip in sanitizing solution, and brush the bore of dispense nozzles

NOTE: Repeat this procedure for each nozzle separately

When reassembling parts, be sure to align arrow on frother disk with flat on whipper motor shaft, and rotate tab on whipper base clock wise to the vertical position to lock mixing chamber

Close the front door to resume normal operation
