Bunn Brewer 44400.0100

Warning: Only perform this procedure when the machine signals a paper roller full condition and locks out brewing.

Confirm the machine has signaled a paper roller full condition and locked out brewing.

Press and hold the BUNN logo icon at the top of the screen for 3 seconds to access the SERVICE ACCESS screen.

Confirm access to the SERVICE ACCESS screen.

Press & hold the ADVANCE PAPER button for 3 seconds to dispense all of the used grounds. NOTE: The DOOR MUST REMAIN CLOSED!

Confirm all used grounds have been dispensed.

Open the brewer door and cut or tear the filter.

Confirm the filter has been cut or torn.

Turn the handle for the paper take-up roller to the vertical position.

From the CARE AND CLEANING screen, select the RINSE tab to prepare the equipment for rinsing the Brew Funnel and Brew Box

Follow the directions shown on the screen

The CARE AND CLEANING screen will show a progress bar with the message 'Please Wait - Rinsing'

NOTE: If for any reason the rinsing process needs to be halted, press the STOP button

The machine will pause. The user will then need to press the reset button to reset the machine. Insure the 64oz (2 liter) pitcher is ready to capture any water that is dispensed during the reset sequence

Sign off on the daily brewer tab cleaning

From the SERVICE ACCESS screen, press the CARE AND CLEANING button

From the CARE AND CLEANING screen, select the CLEAN tab to prepare the equipment for cleaning of the brew system

Press the START button to begin

Once the START button has been pressed, a message saying 'Please do NOT open door until prompted' will be displayed

Once the CONTINUE button has been pressed, the operator will be presented with a new screen indicating that the cleaning process has begun, and to 'Please Wait... Removing Loose Grounds'

During the 'Removing Loose Grounds' step, there is no operator interaction

Press the CONTINUE button to resume the cleaning process

Following the steps to add a Cleaning Tablet

Press and hold the BUNN logo at the top of the screen for 3 seconds to access the SERVICE ACCESS screen

From the SERVICE ACCESS screen, press the CARE AND CLEANING button

Use a damp cloth rinsed in any mild, non-abrasive, liquid detergent for cleaning all surfaces on Bunn-O-Matic equipment

Exterior Surfaces cleaned without use of any abrasive materials

Exterior surfaces of the dispenser wiped down with a soft, dry cloth to maintain the luster of the stainless steel finish

Stainless steel interior surfaces of the dispenser washed with warm, soapy water and rinsed with warm, clear water

If the water is hard, dispenser wiped dry with a soft cloth to prevent spotting

Acrylic door panel cleaned with cleaning cloth provided

Warning: For trained personnel only

Brew Funnel in the upper position?

Rubber Hose disconnected from the Brew Funnel?

Funnel removed from the funnel arms?

Funnel cleaned with non-abrasive, liquid detergent?

Funnel reinstalled under the Coffee Chute?

Metal Pins placed on the Flat Springs?

Funnel snapped into the funnel arms?
