Warning: Before any work on the machine itself, pull the mains plug.

The rated speed of the accessory must be at least equal to the maximum speed marked on the power tool. Accessories running faster than their rated speed can break and fly apart.

Is the residual material of the grinding wheel less than 10 mm?

Loosen the 3 screws of cover 1 and remove cover 1. Hold the grinding wheel wearing protective gloves and unscrew the clamping nut 2 from the grinder spindle 5.

Note: The grinder spindle 5 on the left side of the machine has a left-hand thread.

Remove the clamping flange 3 and the grinding wheel from the grinder spindle 5.

The new grinding wheel is mounted in reverse order. Place the cover 1 firmly onto the housing and tighten with the 3 screws.

Dress used and out-of-centre grinding wheels with a whetstone (accessory) before continuing to use them.

Sign off on the grinding wheel replacement

Warning: Before any work on the machine itself, pull the mains plug.

Machine and ventilation slots clean

If the replacement of the supply cord is necessary, this has to be done by Bosch or an authorized Bosch service agent in order to avoid a safety hazard.

Is the supply cord replacement necessary?

Sign off on the bench grinder maintenance
