Atlas Copco Stationary Air Compressor SF 8 Multi

Remove the filter cover and filter

Fit a new filter and reinstall the cover

NOTE! Inspect ball valve mechanism of condensate trap every 5000 Hours / 1 Year

NOTE! Replace V-belt(s) every 5000 Hours / 1 Year

NOTE! Grease orbiting scroll bearing every 5000 Hours / 2 Year

Sign off on the air filter replacement

Warning: Never run the compressor without safety valve

Did the valve open at the pressure marked on the valve?

If the valve did not open, describe the issue

Did you consult Atlas Copco if the valve did not open?

Did you test the electrical components/shut-down switch?

Sign off on the safety valve testing

Warning: No adjustments are allowed. Never run the compressor without safety valve

Safety valve operational after unscrewing the knurled cap one or two turns

Safety valve operational after retightening the cap

Sign off on the safety valve operation

NOTE! On SF Full-Feature, check dewpoint every 1 Day

Sign off on the daily drain condensation

Remove the filter cover and filter

Check more frequently if operating in a dusty atmosphere

Replace a dirty or damaged filter by a new one

NOTE! Check pressure drop over Atlas Copco filters every 500 Hours / 3 Month
