Atlas Copco Stationary Air Compressor SF 6 Multi

Warning: No adjustments are allowed. Never run the compressor without safety valve

Did the valve open at the pressure marked on the valve?

If the valve did not open, describe the issue

Did you test the electrical components/shut-down switch?

Sign off on the safety valve testing

Compressor element fan cleaned?

Compressor element fins cleaned and seals replaced?

Sign off on the maintenance completion

Upload a photo of the removed filter cover and filter

New filter fitted and cover reinstalled?

NOTE! Inspect ball valve mechanism of condensate trap every 5000 Hours / 1 Year

NOTE! Replace V-belt(s) every 5000 Hours / 1 Year

NOTE! Grease orbiting scroll bearing every 5000 Hours / 2 Year

Sign off on the air filter replacement

Warning: Always wear protective gear while cleaning the coolers.

If not, proceed with the following steps.

Was the dirt removed using a fibre brush?

Never use a wire brush or metal objects.

Was the cooler cleaned by air jet in reverse direction of normal flow?

Is it necessary to wash the coolers with a cleansing agent?

Sign off on the cooler cleaning

Warning: Stop the compressor before starting the inspection

Note: Check more frequently if operating in a dusty atmosphere

Did you replace a dirty or damaged filter with a new one?

Note: Check pressure drop over Atlas Copco filters every 500 Hours / 3 Month

Sign off on the air filter inspection
