Atlas Copco Oil-Injected Rotary Screw Compressor GA7VSD+FF

Warning: Ensure the compressor is stopped and voltage is switched off before proceeding.

Compressor stopped and voltage switched off?

Remove the cover of the air filter (AF) by turning it anti clockwise.

Fit the new element and the cover.

Reset the air filter service warning.

Check condition of the air intake hose between air filter and compressor element

Check operation of cooling fans of converter

Check blow-off solenoid valve after stopping and pressing the emergency stop button

Compressor stopped and air outlet valve closed

Upload a photo of the condenser inlet before cleaning

Dirt removed from the condenser inlet with a vacuum cleaner

Condenser cleaned with an air jet in the reverse direction to normal flow using low pressure air

Compressed air nozzle kept more than 30 cm away from the condenser

Upload a photo of the condenser after cleaning

Dust removed from inside the dryer with a vacuum cleaner

Water or solvents not used for cleaning the condenser

Atlas Copco's Roto-Inject Fluid is a specially developed lubricant for use in single stage oil-injected screw compressors.

Its specific composition keeps the compressor in excellent condition.

Roto-Inject Fluid can be used for compressors operating at ambient temperatures between 0 ̊C (32 ̊F) and 40 ̊C (104 ̊F).

If the compressor is regularly operating in ambient temperatures above 35 °C (95 °F), oil lifetime is reduced significantly.

In such case use Roto-Xtend Duty Fluid for a longer interval for oil exchange.

If the compressor is regularly operating in ambient temperatures above 35 °C (95 °F), oil lifetime is reduced.

Select the ambient temperature range

Select the element outlet temperature range

Based on the selected temperature ranges, follow the appropriate exchange interval.

Warning: Ensure the compressor is stopped, the air outlet valve is closed and the voltage is switched off before starting the procedure.

Cover all parts under the coolers

Remove the service plate at the fan compartment

Remove dirt from the coolers with a fibre brush. Brush in the direction of the cooling fins

Remove dirt from the fan with a fibre brush

Clean with an air jet in the reverse direction to normal flow

Is it necessary to wash the coolers with a cleaning agent?

Mount the service plate (1) at the fan compartment
