Atlas Copco Oil-Injected Rotary Screw Compressor GA45+

Warning: Never run the compressor without safety valve

Safety valve unscrewed one or two turns and retightened

Compressor depressurised before removing the valve

Safety Valve tested on a separate air line

Did the valve open at the set pressure stamped on the valve?

If the valve did not open at the set pressure, it needs to be replaced

Sign off on the safety valve testing

Condensate discharged when pressing the test button on top of the electronic water drain?

On compressors with integrated dryer, stop the compressor, close the air outlet valve and switch off the voltage.

Dirt removed from the condenser inlet with a vacuum cleaner?

Cleaned with an air jet in the reverse direction of the normal flow?

Use low pressure air. Keep the compressed air nozzle more than 30 cm away from the condenser to avoid damaging the of condenser fins.

Dust removed from inside the dryer with a vacuum cleaner?

Do not use water or solvents to clean the condenser.

Sign off on the monthly maintenance

Check coolers. Clean if necessary

Remove the air filter element and inspect. If necessary, clean using an air jet. Replace damaged or heavily contaminated elements

Check the filter element of the electric cabinet. Replace if necessary

Check air filter service indicator

Check that condensate is discharged during operation

On water-cooled units: check for cooling water flow

Warning: Always shut off all power to the unit before servicing.

Electronic water drain(s) in working condition?

If not, proceed with the following steps:

Select the type of service kit used

Service kits include all necessary parts for servicing the component.

Service kit successfully installed?

Note: Using genuine Atlas Copco parts ensures optimal performance and longevity of the unit.

Select the type of lubricant used

Lubricant successfully applied?
