Atlas Copco Drill Rig ROC L8(30)

Warning: Cleaning should be done by trained personnel only

Rotating the cyclone and opening the cover plate

Opening the two hatches on the intermediate chamber

Opening the Jones riffle splitter inspection hatch

Swinging the cone splitter out of the way

Warning: Rotary actuators, cylinders and shafts must not be cleaned with high-pressure washing

Sign off on the daily rig cleaning

Instructions for checking the oil level

Has the drill rig been standing still for 10 minutes?

Check the oil level gauge. Enter the reading.

Is the gauge in the green zone?

Sign off on the oil level check

Check drill rig for any signs of leaks, damage, breakage or cracks

Check working lights front, rear and on feeder

Any fault indicator symbols shown?

If a fault indicator shows in the status field, stop the drill rig and rectify the fault

Check the filter in the filter holder and suction hose

Check the drill-steel support's drill gasket

Sign off on the daily drill rig service

Warning: Ensure the drill rig has been standing still for one hour before proceeding

Sign off on the compressor tank draining

Check if the lubricating pressure deviates from the percussion pressure

Is the needle on the pressure gauge in the red zone?

If the needle is in the red zone, the return oil filter must be replaced

Contact details of the service technician

Sign off on the pressure gauge inspection
