Atlas Copco Drill Rig ROC L6(30)

Instructions for checking the oil level

Has the drill rig been standing still for 10 minutes?

Check the oil level gauge. Enter the reading.

Is the gauge reading in the green zone?

Sign off on the oil level check

Lubrication oil seeping out of the drill bit

Plank placed in front of the drill bit and air flushing activated

Plank becomes oily after a short time

Warning: Ensure the drill rig has been standing still for one hour before proceeding

Sign off on the compressor tank draining

Check if the lubricating pressure deviates from the percussion pressure

Is the needle on the pressure gauge in the red zone?

If the needle is in the red zone, the return oil filter must be replaced

Contact details of the service technician

Sign off on the pressure gauge inspection

Check each emergency stop button individually

Before checking the next emergency stop button the previous one must be reset before restarting

Check that no fault indicator symbols come on

If a fault indicator shows in the status field, stop the drill rig and rectify the fault

Sign off on the emergency stop button check
