Atlas Copco Compressed Air Filter PD380+

NOTICE! When the filter has to process air with a temperature higher than the specified maximum temperature, the filter's lifetime will be reduced considerably

NOTICE! The hand-tool icon on the figure indicates the items provided in a dedicated filter kit

Is the filter isolated from the compressed air flow?

Is the old drain taken out by loosening the plastic drain nut (max. 3.5 Nm)?

Is the used drain and securing nut discarded?

Is the new drain installed and secured by tightening the plastic drain nut (max. 3.5 Nm)?

Is the filter housing used again for filtering purposes?

Sign off on the drain replacement

When maintaining the filter, keep in mind the following

• On filters with manual drain valve, open the latter at regular intervals to evacuate collected dust or liquid

• In case an automatic drain valve or a solenoid timer drain is installed, manual draining can be carried out by turning the connection nipple of the automatic drain valve counterclockwise

NOTICE! When the filter has to process air with a temperature higher than the specified maximum temperature, the filter's lifetime will be reduced considerably

- Following steps can be taken to change the filter to inPASSTM mode for a service event

Unlock and remove the lock from the lock-out feature

Slide the lock-out feature sideways to free the hexagonal nut for rotational movement

WARNING! For safety reasons, the inPASSTM should never be operated while the bowl is dismounted (fully or only partly) from the head
