Atlas Copco Air Dryer CD 60+

Create an account to install this asset package.

Maintenance Plans for Atlas Copco Air Dryer Model CD 60+

Integrate maintenance plans directly into your work orders in MaintainX.

40000 Hourly/5 Yearly Air Dryer Maintenance

• Check for damaged wiring or loose connections.

• Check for air leaks.

• Replace the in- and outlet filter cartridges.

• Replace the silencers.

• Exchange the dew point sensor. The certificate is valid only one year. Contact the supplier of your equipment for re-calibration of the PDP sensor. Consult ECB AII 0298.

• Replace desiccant

Always replace all o-rings, seals and nylon washers that come free when executing the scheduled maintenance.

Every 5 years: when replacing the desiccant, following inspections are to be carried out:

• Inspection of outside and inside of the material for excessive and local corrosion,

Run this procedure

8000 Hourly/1 Yearly Air Dryer Maintenance

Check for damaged wiring or loose connections

Check for air leaks

Replace the in- and outlet filter cartridges

Replace the silencers

Exchange the dew point sensor

The certificate is valid only one year. Contact the supplier of your equipment for re-calibration of the PDP sensor. Consult ECB AII 0298.

Sign off on the air dryer maintenance

Run this procedure

8000 Hourly Service Counter Resetting

Close off the dryer as described in the stopping procedure, see section Operating instructions.

Switch off the dryer by putting switch S1 to ‘Off’ position. LED (2, Dryer operating) will extinguish.

Perform the service plan as scheduled.

If the service warning LED (9) is already alight, go directly to the next step.

If maintenance is being carried out before the service alarm appears (every 8000 hrs), the reset procedure needs to be activated before the service counter can be reset to 0.

Place the service magnet during 3 seconds over the indicated area (A) of the control panel, in the middle of the left tower. The service warning LED (9) will light up.

Reset the timer card by putting the service magnet over the indicated area (A) of the control panel during 5 s. The service alarm LED extinguishes. The service counter has now been reset to 0.

Also the counter to switch towers will be reset to 0 (only visible in case of timer control).

Restart the dryer by switching switch S1 to ‘On’. The counter will restart, the dryer operating LED (2) is alight, and the drying and regeneration LED’s indicate the cycling of the dryer.

Run this procedure

4000 Hourly/6 Monthly Air Dryer Maintenance

Check for damaged wiring or loose connections

Check for air leaks

Replace the in- and outlet filter cartridges

Replace the silencers

Sign off on the air dryer maintenance

Run this procedure
