Atlas Copco Oil-Sealed Rotary Screw Vacuum Pump GHS 350 VSD+Turbo

Create an account to install this asset package.

Maintenance Plans for Atlas Copco Oil-Sealed Rotary Screw Vacuum Pump Model GHS 350 VSD+Turbo

Integrate maintenance plans directly into your work orders in MaintainX.

4000 Hourly / 1 Yearly Pump Maintenance

Change oil. In medium and harsh applications an optional 500 hrs oil sample is recommended. In Medium condition interval should be 2000 Hours while in Harsh condition interval should be 1000 Hours

Change oil filter. In Medium condition interval should be 2000 Hours while in Harsh condition interval should be 1000 Hours

Replace the air filter elements. In Medium condition interval should be 2000 Hours while in Harsh condition interval should be 1000 Hours

Clean the scavange line and blow out the restriction nozzle. In Medium condition interval should be 2000 Hours while in Harsh condition interval should be 1000 Hours

Replace the oil seperator elements. In Medium condition interval should be 4000 Hours while in Harsh condition interval should be 2000 Hours

Check pressure and temperature readings. In Medium condition interval should be 4000 Hours while in Harsh condition interval should be 2000 Hours

Check operation of cooling fans of converter and clean heatsink. In Medium condition interval should be 4000 Hours while in Harsh condition interval should be 2000 Hours

Check vacuum control valve solenoid and gasballast solenoid valve. In Medium condition interval should be 4000 Hours while in Harsh condition interval should be 2000 Hours

Clean coolers. In Medium condition interval should be 4000 Hours while in Harsh condition interval should be 2000 Hours

Run this procedure

1 Monthly Pump Maintenance

Remove the air filter elements and inspect

Replace damaged or heavily contaminated elements

Check for possible air and oil leakages

Run this procedure

24000 Hourly Pump Maintenance

Motor overhaul completed?

Change lipseal assembly completed?

Replacement of tubes completed?

Select the condition of the element

Element overhaul in Normal condition every 48000 Hours, in Medium condition every 36000 Hours and in Harsh condition every 24000 Hours

Sign off on the pump maintenance

Run this procedure

8000 Hourly / 2 Yearly Pump Maintenance

NOTE! All these instructions are based on Normal condition. In Medium condition interval should be 6000 Hours while in Harsh condition interval should be 4000 Hours

Replace the filter element of electric cabinet

Replace the thermostatic valve

Test pressure switch

Replace membrane of vacuum control valve. For non-turbo application every 48000 Hours

Replace vacuum Synthetic fluid. In Medium condition interval should be 6000 Hours

Sign off on the pump maintenance

Run this procedure

3 Monthly Pump Check

Check coolers, clean if necessary

Check the filter elements of the electric cabinet. Replace if necessary

Check the silencer of the vacuum control valve, clean if necessary

Run this procedure
