Yaskawa Compact V/f Control Drive CIMR-JC2A0002B

Create an account to install this asset package.

Maintenance Plans for Yaskawa Compact V/f Control Drive Model CIMR-JC2A0002B

Integrate maintenance plans directly into your work orders in MaintainX.

1 Yearly Compact V/f Control Drive Inspection

WARNING! Electrical Shock Hazard. Do not connect or disconnect wiring while the power is on.

Failure to comply can result in serious personal injury.

Before servicing the drive, disconnect all power to the equipment.

The internal capacitor remains charged even after the power supply is turned off.

The charge indicator LED will extinguish when the DC bus voltage is below 50 Vdc.

To prevent electric shock, wait at least one minute after all indicators are OFF and measure the DC bus voltage level to confirm safe level.

1. Main Circuit Periodic Inspection

General: Inspection Points:

• Inspect equipment for discoloration from overheating or deterioration.

Run this procedure

1 Daily Compact V/f Control Drive Inspection

WARNING! Electrical Shock Hazard. Do not connect or disconnect wiring while the power is on.

Failure to comply can result in serious personal injury.

Before servicing the drive, disconnect all power to the equipment.

The internal capacitor remains charged even after the power supply is turned off.

The charge indicator LED will extinguish when the DC bus voltage is below 50 Vdc.

To prevent electric shock, wait at least one minute after all indicators are OFF and measure the DC bus voltage level to confirm safe level.

Motor: Inspect for abnormal oscillation or noise coming from the motor, if confirmed:

• Check the load coupling.

• Measure motor vibration.

Run this procedure

Initial 3 Monthly Compact V/f Control Drive Inspection

WARNING! Electrical Shock Hazard. Do not connect or disconnect wiring while the power is on.

Failure to comply can result in serious personal injury.

Before servicing the drive, disconnect all power to the equipment.

The internal capacitor remains charged even after the power supply is turned off.

The charge indicator LED will extinguish when the DC bus voltage is below 50 Vdc.

To prevent electric shock, wait at least one minute after all indicators are OFF and measure the DC bus voltage level to confirm safe level.

1. Main Circuit Periodic Inspection

General: Inspection Points:

• Inspect equipment for discoloration from overheating or deterioration.

Run this procedure

10 Yearly Electrolytic Capacitors Replacement

Only use Yaskawa replacement parts for the appropriate drive model and revision.

Estimated performance life based on specific usage conditions.

Usage conditions for estimated performance life: Ambient temperature: Yearly average of 30 °C, Load factor: 80% maximum, Operation time: 12 hours a day.

Capacitors replaced with Yaskawa parts?

Enter the ambient temperature

Enter the load factor

Enter the operation time

Sign off on the capacitor replacement

Run this procedure
