Toyota Toyota Forklift 02 - 5FD18 02 - 5FD18

Measure battery fluid specific gravity

Inspect open-circuit in open plug

Inspect open-circuit in intake heater

Sign off on the electric system maintenance

Inspect cracks at fork root and welded part while forklift is new

Inspect wear and damage of mast support bushing

Inspect wear and damage of roller pins

Measure relief pressure in oil control valve

Inspect damage and cracks of frame, cross members, etc.

Sign off on the 2000 Hours / 12 Months Maintenance

Measure tire inflation pressure of the wheels

Inspect for tire cuts, damage, and uneven wearing

Tighten for loose rim and hub nuts

Inspect for metal chips, pebbles, or foreign matter trapped in tire grooves

Inspect rim, side bearing, and disc wheel for damage

Inspect for abnormal sound and looseness in the front wheel bearing

Inspect for abnormal sound and looseness in the rear wheel bearing

Measure looseness of axle beam in vehicle longitudinal direction while forklift is new

Inspect linkage wear and mounting condition of the rods, links and arm

Inspect damage of power steering hose

Inspect cracks and deformation in knuckle

Measure wheel alignment in steering shaft

Measure steering shaft left and right turning angle

Sign off on the steering system inspection

Inspect proper starting and abnormal noise

Measure rotating condition at idling

Measure rotating condition during acceleration

Retighten cylinder head bolt loosening

Inspect PCV system for clogging and damage in PCV valve and piping

Measure no-load maximum RPM of governor
