Toyota Forklift 62 - 5FD23

Measure tire inflation pressure of the wheels

Inspect for tire cuts, damage, and uneven wearing

Tighten for loose rim and hub nuts

Inspect for metal chips, pebbles, or foreign matter trapped in tire grooves

Inspect rim, side bearing, and disc wheel for damage

Inspect for abnormal sound and looseness in the front wheel bearing

Inspect for abnormal sound and looseness in the rear wheel bearing

Measure looseness of axle beam in vehicle longitudinal direction while forklift is new

Inspect head guard for cracks at welded portions

Inspect head guard for deformation and damage

Retighten for loosening of mounting in the back-rest

Inspect back-rest for deformation, cracks, and damage

Inspect the function and mounting condition of the lighting system

Inspect horn function and mounting condition

Inspect the function and mounting condition of the direction indicator

Inspect the functions of the instruments

Inspect the function and mounting condition of the backup buzzer

- Inspect function, wear, damage, leak and mounting looseness in Master cylinder and wheel cylinder

- Inspect Wear of shoe sliding portion and lining

- Inspect Shoe operating condition

- Measure Return spring fatigue

- Inspect Automatic adjuster function

- Inspect Backing plate for deformation, cracks and damage

- Retighten Backing plate loose mounting;

Inspect cracks at fork root and welded part while forklift is new

Inspect wear and damage of mast support bushing

Inspect wear and damage of roller pins

Measure relief pressure in oil control valve

Inspect damage and cracks of frame, cross members, etc.

Sign off on the 2000 Hour / 12 Month Maintenance

Measure battery fluid specific gravity

Inspect open-circuit in open plug

Inspect open-circuit in intake heater

Sign off on the electric system maintenance
