Toyota Forklift 02-7FDF15
Create an account to install this asset package.
Maintenance Plans for Toyota Forklift Model 02-7FDF15
Integrate maintenance plans directly into your work orders in MaintainX.
1000 Hour / 6 Month Replacement
Fuel filter replaced
Torque converter oil filter replaced
Torque converter oil replaced
Hydraulic oil filter replaced
Hydraulic oil replaced
Brake fluid replaced
Spark plugs replaced
DPF Muffler back pressure sensor inline filter replaced (OPT)
2 Year Replacement
Select the parts replaced
Note: Chains and DPF Muffler filter are replaced every 3 years
Note: SAS swing lock cylinder is replaced every 10000 hours
Sign off on the replacement procedure
2000 Hour / 12 Month Engine System Maintenance
Measure Valve clearance (IDZ-II·2Z)
Measure main body compression
Retighten cylinder head bolt loosening
Inspect muffler rubber mount
Measure Injection nozzle injection pressure and spray status
Inspect radiator rubber mount
2000 Hour / 12 Month Material Handling System Inspection
Inspect cracks at fork root and welded part while forklift is new
Inspect wear and damage of mast support bushing
Inspect wear and damage of roller pins
Measure relief pressure in oil control valve
Inspect plug cord internal discontinuity
Clean DPF valve in DPF Muffler
Sign off on the inspection
1000 Hour / 6 Month Electric System Maintenance
Measure ignition timing
Measure battery fluid specific gravity
Inspect open-circuit in glow plug
Inspect open-circuit in intake heater
Inspect DPF Muffler filter
Sign off on the electric system maintenance
