Toyota Forklift 02-6FDA 15

Retighten differential bolt loosening

Inspect Looseness at spline connections

Inspect Looseness of universal joint

Inspect Twisting and cracks of axle shaft

Sign off on the power transmission system maintenance

Power steering rubbers parts replaced

Brake fluid reservoir tank hose replaced

Torque converter rubber hoses replaced

Note: Chains are replaced every 3 years

Sign off on the 2 year replacement

Inspect linkage wear and mounting condition of the rods, links and arm

Inspect damage of power steering hose

Inspect cracks and deformation in knuckle

Measure wheel alignment in steering shaft

Measure steering shaft left turning angle

Measure steering shaft right turning angle

Sign off on the steering system inspection

Inspect head guard for cracks at welded portions

Inspect head guard for deformation and damage

Retighten for loosening of mounting in the back-rest

Inspect back-rest for deformation, cracks, and damage

Inspect the function and mounting condition of the lighting system

Inspect the function and mounting condition of the horn

Inspect the function and mounting condition of the direction indicator

Inspect the functions of the instruments

Inspect the function and mounting condition of the backup buzzer

Measure tire inflation pressure of the wheels

Inspect for tire cuts, damage, and uneven wearing

Tighten for loose rim and hub nuts

Inspect for metal chips, pebbles, or foreign matter trapped in tire grooves

Inspect rim, side bearing, and disc wheel for damage

Inspect for abnormal sound and looseness in the front wheel bearing

Inspect for abnormal sound and looseness in the rear wheel bearing

Sign off on the drive system maintenance
